The layout editor changes
For any of you who are interested in editing layouts but haven't been following the test patch thread. There are some quite significant changes to the layout editor which make it more usable.

Here's a description of the new changes and the reasons behind the changes:
Here's a description of the new editor changes and the reasons behind the changes:
The layout editor changes
The layout editor has changed. It is now more powerful and works more like other editors.

It now uses a CUT / COPY / PASTE system using the standard Windows keys CTRL+X/C/V

This is different from the old editor style which was based on a select / duplicate / move type of logic which had some limitations and caused some problems.

The problem:

The problem in the old system was that when you selected some objects, they were selected in two ways simultaneously.
1) Visible 'in hand' where your mouse was pointing, ready to be placed in the world
2) The original objects you had selected were still selected

This caused some confusion. For example, if you had some blue tyres and you wanted to place some red ones, you might click the colour and that would change the object in your hand as well as the one on the ground, previously placed or selected.

There are various other examples such as modification of concrete object heights and rotation of objects that could be confusing or annoying because of the old selection method.

The solution:

The updated editor moves to a different editor logic that should be more familiar because of its similarity with other editors. You can cut, copy and paste.

The real improvement now is that there is a complete separation between the world objects that have been selected, and a selection of objects 'in hand'. Only one of these types of selection is active at any time, so if you make any changes to their colour, dimensions, heading, altitude then it only affects the one active selection.

How to use it:

You create a real world selection, as before, by clicking on object selection buttons. There are two ways to select multiple objects.

1) Hold CTRL and click on object selection buttons
2) Hold CTRL and draw a selection rectangle using the left mouse button

After making your selection you can adjust it in various ways using the on screen buttons or keys.

Maybe you would like to duplicate the selected objects. Press COPY and you will see a live selection in hand. Point to where you would like to place the objects and press PASTE or O to put the new objects there.

Maybe you would like to move your selected objects. There are two ways to do this.

1) Press CUT. The original objects are deleted and you will see them as a live selection in hand located at the mouse cursor. You can now make modifications to the selection as required before pasting or placing it in a new location.
2) Press COPY. You will see a live selection in hand while the original objects remain in the world. Make any changes to the selection then press M to move the original objects to their new position.

You can paste a copied selection in two ways:

1) O key: Place objects and keep a selection in hand to be placed again
2) PASTE: Paste the objects and the new objects will be selected, not leaving a selection in hand

Note: you can switch between the two selection styles by pressing COPY.

1) Real world objects selected -> press COPY -> now you have a selection in hand
2) In hand selection -> press COPY to UN-COPY the selection, i.e. reverts to the world object selection

Note: new PGUP and PGDN keys to adjust height for concrete and other floating objects.

Test patch download: EDIT: This is now in the official version 0.6T
Last edited by Scawen, .
Here are some more fixes and updates for the layout editor.

You should find the O key seems similar to how it worked in the old version. In reality it's not the same at all. Because in the old version, you had BOTH the objects 'in hand' selected and the world objects were still selected at the same time, which caused various problems and limitations that users would learn to work around.

In today's version, after pressing O, only the objects 'in hand' are selected. If you want the newly placed world objects to be selected, as in yesterday's version, use PASTE which is CTRL+V.

You can also switch between the 'in hand' and 'world objects' selection styles by using COPY (CTRL+C).


World objects selected, press COPY -> objects now selected in hand
Clipboard objects selected, press COPY -> it's really UN-COPY - reselects the world objects

Changes from 0.6R13 to 0.6R14 :

Layout editor :

Place objects (O) key is now equivalent to PASTE then COPY
COPY key is now reversible so you can reselect the copied objects
FIX : Sometimes marshall type could not be selected before placing
FIX : Real world objects could still be selected after a full clear
Quote from Draggo :and mutch slower. sorry but old "system" was more faster to use eg.
Select object > O > rotate > O > rotate > O > rotate > O > etc

and now its
Select object > O > CTRL+C > rotate > O > CTRL+C > rotate > O > CTRL+C > rotate > O > etc

In one sense you can still do it just as fast.

Select object > O > rotate actual placed object > O > rotate actual placed object

But I do understand that there one thing missing - the object you are about to place with the O key isn't visible (unless you press CTRL+C first). So it's harder to place it with the precision you might want.

I was thinking of one more possibility.
Maybe the O key and CTRL+V could act differently?
I'm not sure if this is a good idea yet but what I'm thinking is:

O : place object and copy immediately. Now the 'in hand' object is visible (but new world object is not selected).

CTRL+V : place object(s) and leave the new world object(s) selected.

So O would be equivalent to CTRL+V then CTRL+C. I suppose that O would be recommended if you are placing single objects (because the single object is very easy to re-select if you made a mistake) but CTRL+V would be the safer method when you are placing multiple selected objects and are likely to make an adjustment after placing them.
Quote from Racon :Is the clipboard emptying on paste by design? It would be handier I think to leave it for multiple pastes, as we have C to clear it when we need to.

Yes, because you can only have a world selection or a clipboard selection but not both, which is the solution to various problems. If it went straight to clipboard selection by default then you would have to re-select the newly placed world objects if you needed to adjust them for any reason.

You can do multiple pastes by pressing O or CTRL+V again, the only difference is that you can't see the selection in hand before you press O. You can make it visible by pressing CTRL+C but that is not required.

[EDIT: one quote and answer removed - better answer below]

Quote from iceman121 :My biggest peeve with the layout editor is the increment that it got with the headings and positioning. The heading of the object has an increment of 1.4, and when I'm trying to match the object's heading to something else, it looks extremely uneven for me.

Also the object position has an increment starting with 0.06 then gets higher the more you move it.

This could be me just being too OCD about it, but it really bothers me nonetheless.

I understand that but there is a good reason for it.

This is because the layout objects are squeezed into a tiny 8 bytes each to allow it to be quickly downloaded as you join a server. That is the reason for the restricted resolution. It's not new with this test patch.
Last edited by Scawen, .
I'll answer the other posts later but I've got an answer for this one.

Quote from sicotange :It happens anywhere on track but weirdly Rockingham, Autocross and Westhill are unaffected.

OK, I've got that original bug now with the invalid position.

EDIT: I had written an explanation here but it turns out the explanation was wrong. Anyway I can reproduce the bug so I'll fix it. Smile

Quote from sicotange :This bug seems to affect Restricted areas and InSim checkpoints. Or this is a different one. How to reproduce:
• Make sure all layout objects are cleared
• press SHIFT + U
• click InSim checkpoint
• click finish line
• press O
• type /axclear
• click finish line, 1st checkpoint, 2nd checkpoint or 3rd checkpoint

InSim checkpoint is added.

Thanks, that seems to be a different bug.
Last edited by Scawen, .
Quote from Racon :I don't see the preview object here either, after pressing O or pasting with ^V. I have to click the object name in the menu again to get it.

I notice you said the ^C/V will replace O/M, but currently both still work. Could we keep O/M and have both ways? I'm not a fan of shift keys if there's an alternative, even if there's a lot of muscle memory there Wink

Please read my updated and edited explanation a couple of posts above.

It's a new way of thinking and I've been developing it for several days now.

There's more to it than you realise and it's better than you think it is so far.
Also now the rotate keys (, / .) can work on the selected object in hand or the selected world objects, as required. You can use SHIFT+rotate key to rotate in steps.

Don't forget to use PGUP and PGDN which also work on the clipboard or world selection as expected.
Quote from sicotange :I tried from a fresh install in several modes. It still happens but interestingly not on all tracks.

Tracks I tested where problem occurs:
• BL1X 1
• KY1X 1
• SO1X 1
• AS1X 1
• FE1X 1
• KY1X 1

Tracks I tested where problem doesn't occur:
• AU1X 1
• RO1X 1

Please can you attach a layout in which you can't select a marshall?

I've attached a layout file at SO1X with two visible marshalls and I can select them, mnve, delete as expected.

Quote from Draggo :I do not see where and how i add a next object

Adding new object

adding next (this same) object

It's different from the old way. In the old editor, there were visible objects "in hand" and they were the same objects still visible in the world. This caused some problems, such as you could not change the colour of an object before you placed it, without also changing the colour of the object that you had selected to copy. And if you made adjustments to the object in hand, it would also be adjusting the object that had been placed.

Now there is a complete separation between these two types of selection. Either there are selected objects in the world, or there are selected objects in the "clipboard" which are visible where your mouse is pointing. Not both at the same time. You go from world selected objects to clipboard selection by pressing COPY (CTRL+C) or CUT (CTRL+X).

When you have selected objects in the world and you want to copy them, you can press CTRL+C to copy. Now, just like most editors, there is CTRL+C CTRL+V and CTRL+X available.

So now you need to think more like any other editor, and forget a bit how it used to be.

CTRL+V (paste) and O are really the same now. The M key still works and you can also press O to duplicate objects. So some of the old functions still work but it is definitely different now.

After a while you will get used to it and I'm sure you will find it is more powerful and useful than before.
Last edited by Scawen, .
Quote from sicotange :Another great patch that should please InSim developers and autocross editors Smile

You can't select non-invisible marshalls (marshall, point left, point right). You get "Can't move : invalid position".

Same issue with InSim checkpoints. Interestingly, the problem goes away when you add 1 invisible marshall or 1 InSim checkpoint finish line.

Thanks for the bug report, but I can't reproduce it. It seems I can select them as expected.
Test Patch R13 is now available for testing.

The layout editor has been updated a lot so if you ever use the layout editor, please give it a go!

Changes from 0.6R12 to 0.6R13 :

Layout editor :

New cut / copy / paste system replaces old duplicate / move system
PGUP and PGDN can now be used to adjust Z value of selected objects
C key now clears selected object type as well as selected objects
It is now possible to set marshall circles to have zero diameter
Objects and marshall circles can now be selected at the same time
You can hold SHIFT to keep objects selected when exiting edit mode

Interface :

Added two more translation strings to avoid misleading messages
Additional translation strings for new functions in layout editor
Clip mouse to screen is now CTRL+M as CTRL+C is now used for copy
More translations updated - Thank you translators!

InSim :

New value PMO_GET_Z for IS_AXM packet to report Z values
Simplified SubMode values for free view in IS_CIM

Misc :

New check for corrupted 3D models to avoid possible crash on load
The PMO_GET_Z packet and other InSim changes are now available for testing in R13 along with a significant update in the layout editor.
Lucky you're not planning my work time then, or you wouldn't get all the super new improvements I've been working on!
There are no turbo sounds in the Demo.

Please buy a license if you would like to use a turbo car.

If people do not pay for the use of the game, our development would be forced to stop and there will be no further updates. Because developers have to pay the bills and eat food.
I think I didn't like the way 255 would mean a maximum height of 63.75 and it seemed that 60m would be a better maximum height. And that allows 15 'reserved' values that could have a special meaning in future.
I am not coming up with an answer for that strange server issue. Has it only happened since you installed R12 on the server? If so, is it easy to revert to R and see if it makes a difference?

I'm guessing it has nothing to do with the new version, as I can't think of any related changes in the code. Does the same problem happen to all guests who join? Are there any other DCon instances on the same server computer? I wonder if it could be something to do with the computer time clock, running slow or fast. Can the server computer be restarted?
Sorry my estimate was a bit too optimistic.

I ended up making a significant change to the layout editor. It's now based on "cut / copy / paste" instead of "move / duplicate" so it is quite a change and there are a few loose ends to fix.
I implemented it this morning.

A new PMOAction byte for IS_AXM

PMO_GET_Z, // 8 - request Z values / reply with Z values

And the documentation for how it works.

// PMO_GET_Z can be used to request the resulting Zbyte values for given X, Y, Zbyte
// positions listed in the IS_AXM. A similar reply (information only) will be sent
// with adjusted Zbyte values. Index and Heading are ignored and set to zero in the
// reply. Flags is set to 0x80 if Zbyte was successfully adjusted, zero if not.
// Suggested input values for Zbyte are either 240 to get the highest point at X, Y
// or you may use the approximate altitude (see layout file format).

I'm not sure it will be released today, probably not as I've got something else I'd like to have a go at. But then hopefully tomorrow.
Last edited by Scawen, .
Quote from DarkKostas :Scawen i'll just need just 1 more letter for "3h_comfreev". Last word is "προβολή" and the limit spots it at "προβόλ" (for greek translation)

I've now increased all those "Command is for..." strings to 63 characters.

Thanks! Smile
OK, I am mentally tired from trying to get a layout editor improvement finished. You can now select marshalls / circles at the same time as other types of object but that was more complicated than it sounds.

So bear with me being a bit slow! Big grin

Can we get back to the basics, exactly what do you want to do? I understand you are trying to make layouts from a old track work on a new one. And this could be applied to moving a layout from one track to another I guess (e.g. BL car park to WE car park).

Are you trying to run through existing layouts and get all the objects of a certain type set to ground level? In particular concrete objects so you can't use the Zbyte 240?

And are you doing this by your code reading a layout file and passing it into LFS as AXM packets?

If the above is true I'm wondering if the simplest thing could be an InSim packet for local use only, that simply asks for the height for a given ObjectInfo (X,Y, Zbyte) and LFS replies with the Zbyte that would result from that. So you could run through a list of objects one by one and do what you want with the answer?
I don't know much about VOB mods, but some of them can have the correct physics mesh so they can be used online without harming any other players. From the crash address I was given, it looks like the crash was when reading an object, so that's why I'm asking if any of the people who got a crash, were using a modified VOB. But no-one has answered yet so I'm still worried about the possibility it could a be a problem in some standard installations.

Either way, I'd better add a thorough validity check when loading an object because a crash is not acceptable in any case. But it would be reassuring to know that it was caused by a modified VOB, otherwise there's a more serious bug here.
I am just wondering if something special could be done for this.

Possibly a sort of query to find the highest ground position at X, Y.
Or perhaps an object placement packet marked as "set height"

I'm wondering if this can be done at the local level or does it need to work in multiplayer.

Sorry for the fuzzy thinking, I'm busy in the layout editor at the moment so I'm just trying to figure out what would solve it for you, be simple to implement and ideally useful for other situations too.

I've moved our discussion into a spinoff thread and I'll answer there.
Quote from R0ut66 :The test patchs after R9 doesn't work on my PC
It just crashes the game
I'm using windows 7 64 bits

You are the 4tf person we've heard of that got a crash. It's very important that we understandf this, or else there is a possibility of it happening in the official update. So you may be able to help.

Please can you look at this post:

Can you get the crash logs?

And do you have any VOB mods installed?

My main suspicion at the moment is incorrectly formed 3D models (probably VOB). But it's not based on much.
